WindO/I-NV4 User’s Manual 30-17
3 Analog I/O Modules
30
Expansion Modules
■ Minimum and maximum values
The values of Min. and Max. are determined by the set Signal Type and Data Type. The value is stored in the
Data according to values of Min. and Max..
The minimum and maximum values that correspond to the signal type and data types are as follows.
*1 Binary data (12bit) and Optional range (12bit) are displayed only for FC6A-J8A1 and FC6A-J8A4.
*2 Min. and Max. can be configured in the range of -32,768 to 32,767 only when Optional range is configured to Data
Type. However, when PTC Thermistor (threshold) is configured to Signal Type, the range of Min. and Max. is 100 to
10,000. For Optional range, refer to “ Optional range” on page 30-16.
*3 For details, refer to “ PTC Thermistor (Threshold)” on page 30-21.
Signal Type
Data Type
Binary data
*1
Optional
range
*1*2
Celsius
(℃)
Fahrenheit
(℉)
Resistance
(Ω)
Binary data
(16bit)
Optional
range
(16bit)
0 to 10V DC
0 to 65,535 -32,768 to 32,767 ― ― ― 0 to 65,535 -32,768 to 32,767
-10 to +10V DC
-32,768 to 32,767 -32,768 to 32,767 ― ― ― -32,768 to 32,767 -32,768 to 32,767
0 to 20mA DC
0 to 65,535 -32,768 to 32,767 ― ― ― 0 to 65,535 -32,768 to 32,767
4 to 20mA DC
0 to 65,535 -32,768 to 32,767 ― ― ― 0 to 65,535 -32,768 to 32,767
Type K thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ― ― ―
Type J thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 10,000 -3,280 to 18,320 ― ― ―
Type R thermocouple
0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ― ― ―
Type S thermocouple
0 to 65,535 -32,768 to 32,767 0 to 17,600 320 to 32,000 ― ― ―
Type B thermocouple
0 to 65,535 -32,768 to 32,767 0 to 18,200 320 to 33,080 ― ― ―
Type E thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 8,000 -3,280 to 14,720 ― ― ―
Type T thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 4,000 -3,280 to 7,520 ― ― ―
Type N thermocouple
0 to 65,535 -32,768 to 32,767 -2,000 to 13,000 -3,280 to 23,720 ― ― ―
Type C thermocouple
0 to 65,535 -32,768 to 32,767 0 to 23,150 320 to 41,990 ― ― ―
Pt100
0 to 65,535 -32,768 to 32,767 -2,000 to 8,500 -3,280 to 15,620 ― ― ―
Pt1000
0 to 65,535 -32,768 to 32,767 -2,000 to 6,000 -3,280 to 11,120 ― ― ―
Ni100
0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ― ― ―
Ni1000
0 to 65,535 -32,768 to 32,767 -600 to 1,800 -760 to 3,560 ― ― ―
NTC Thermistor
0 to 65,535 -32,768 to 32,767 -900 to 1,500 -1,300 to 3,020 ― ― ―
PTC Thermistor
0 to 65,535 -32,768 to 32,767 ― ― 100 to 10,000 ― ―
PTC Thermistor
(threshold)
*3
1/2/4 ― ― ― ― ― ―
Ohm meter
0 to 65,535 -32,768 to 32,767 ― ― 100 to 32,000 ― ―
Expansion 0 to 20mA
DC
0 to 4,095 -32,768 to 32,767 ― ― ― 0 to 65,535 -32,768 to 32,767
Expansion 4 to 20mA
DC
0 to 4,095 -32,768 to 32,767 ― ― ― 0 to 65,535 -32,768 to 32,767
To Next Page
