WindO/I-NV4 User’s Manual 33-11
2 Word Devices
33
Internal Devices
*11 This is applicable for models with a video interface only.
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
LSD105 Reserved (for O/I Link communication)
LSD106 Slave error information register for O/I Link Master Yes Yes Yes Yes
LSD107 Reserved (for O/I Link communication)
LSD108, 109 Reserved
LSD110, 111 Reserved (for Communication drivers)
LSD112
Register for Communication drivers
For details, refer to the WindO/I-NV4 External Device Setup Manual.
Yes Yes Yes Yes
LSD113 to 119 Reserved (for Communication drivers)
LSD120 to 123
The preset value for Preferred DNS Server. When the value of LSM53
changes from 0 to 1, the values of these device addresses are
written to the MICRO/I. When the power is turned on, the set values
of the project are read to these device addresses.
Yes Yes Yes Yes
Example: When the IP address is 192.168.0.11
LSD120=192, LSD121=168, LSD122=0, LSD123=11
LSD124 to 127
The preset value for Alternate DNS Server. When the value of LSM53
changes from 0 to 1, the values of these device addresses are
written to the MICRO/I. When the power is turned on, the set values
of the project are read to these device addresses.
Yes Yes Yes Yes
Example: When the IP address is 192.168.0.12
LSD124=192, LSD125=168, LSD126=0, LSD127=12
LSD128 to 154 Reserved
LSD155
Event Recording Function Status Information
While data is being recorded after an event occurs with the event
recording function or while recorded data is being saved to the
external memory device, the value of bit 0 changes to 1. It changes
to 0 when the saving operation completes.
No Yes
Yes
*11
No
LSD156 to 164 Reserved
LSD165
Multimedia Function Error Information
0: Normal
1: Specified file does not exist
2: File format is incorrect
3: Specified parameter value is out of range
No Yes
Yes
*11
No
LSD166 to 191 Reserved
LSD192 to 195
The preset value for IP address of the MICRO/I. When the value of
LSM53 changes from 0 to 1, the values of these device addresses
are written to the MICRO/I. When the power is turned on, the set
values of the project are read to these device addresses.
Yes Yes Yes Yes
Example: When the IP address is 192.168.0.1
LSD192=192, LSD193=168, LSD194=0, LSD195=1
LSD196 to 199
The preset value for subnet mask of the MICRO/I. When the value
of LSM53 changes from 0 to 1, the values of these device addresses
are written to the MICRO/I. When the power is turned on, the set
values of the project are read to these device addresses.
Yes Yes Yes Yes
Example: When the subnet mask is 255.255.254.0
LSD196=255, LSD197=255, LSD198=254, LSD199=0
LSD200 to 203
The preset value for default gateway of the MICRO/I. When the
value of LSM53 changes from 0 to 1, the values of these device
addresses are written to the MICRO/I. When the power is turned on,
the set values of the project are read to these device addresses.
Yes Yes Yes Yes
Example: When the default gateway is 192.168.0.24
LSD200=192, LSD201=168, LSD202=0, LSD203=24
LSD204
The External Device ID to change the IP address and the port
number
Yes Yes Yes Yes
