2 Word Devices
33-12 WindO/I-NV4 User’s Manual
*2 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
*12 HG5G/4G/3G/2G-V only
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
LSD205 to 208
The preset value for IP address of external device. When the LSM54
changes from 0 to 1, the values of these device addresses are
written to the MICRO/I. When the value of LSD204 changes, the set
values of the project are read to these device addresses.
Yes Yes Yes Yes
Example: The IP address is 192.168.0.2
LSD205=192, LSD206=168, LSD207=0, LSD208=2
LSD209
The preset value for the port number of the external device. When
the value of LSM54 is changed to 1, the value of this device address
is written to the MICRO/I. When the value of LSD204 changes, the
set value of the project is read to this device address.
Yes Yes Yes Yes
LSD210 to 212 Reserved
LSD213
The preset value for port number for maintenance communication of
the MICRO/I. When the value of LSM53 changes from 0 to 1, the value
of this device address is written to the MICRO/I. When the power is
turned on, the set value of the project is read to this device address.
Yes Yes Yes Yes
LSD214 to 219 Reserved
LSD220
Ethernet port configuration error information
The following bits change to 1 when allocating the port numbers
used by the various Ethernet communications functions has failed.
The bits are 0 when allocating the port numbers was successful or a
function is not used.
Bit 0: Maintenance Communication
Bit 1: Pass-Through
*2
Bit 2: FC4A Series MicroSmart direct connection pass-through
*2
Bit 3: User Communication
Bit 4: Web Server Function
Bit 5: FTP Server Function
Bit 6: FTP Client Function
Bit 7: E-mail Function
Bit 8: External Device Communication 1
Bit 9: External Device Communication 2
Bit 10: External Device Communication 3
Bit 11: External Device Communication 4
Bit 12: BACnet communication
*12
Yes Yes Yes Yes
LSD221 Number of e-mail in "Waiting" status Yes Yes Yes Yes
LSD222
Result of e-mail sending
0: Successfully Completed
1: Parameter error
2: Timeout error (Timeout period: 30 seconds)
3: Authentication error
4: Other error
Yes Yes Yes Yes
LSD223 E-mail number which has been sent Yes Yes Yes Yes
LSD224 to 228 Reserved
LSD229
Specifies the character encoding method used when reading and writing
strings from the Custom Web Page.
0: No Conversion(UTF-8)
1: Japanese (Shift-JIS)
2: Western (ISO 8859-1)
3: Simplified Chinese (GB2312)
4: Traditional Chinese (BIG5)
5: Hangul (KSC5601)
6: Central European (ANSI1250)
7: Baltic (ANSI1257)
8: Cyrillic (ANSI1251)
Yes Yes Yes Yes
LSD230 Number of the FTP server connected to using the FTP client function Yes Yes Yes Yes
LSD231
Number of file transfer successes
The register is set to 0 at the start of file transfers. 1 is added to the
register when a file transfer ends without any errors.
Yes Yes Yes Yes
