WindO/I-NV4 User’s Manual 33-13
2 Word Devices
33
Internal Devices
*9 This is applicable for models with an audio interface only.
*11 This is applicable for models with a video interface only.
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
LSD232
Number of file transfer failures
The register is set to 0 at the start of file transfers. 1 is added to the
register when any error occurs in the file transfer.
Yes Yes Yes Yes
LSD233 to 239 Reserved
LSD240, 241
Version number of the system software
Yes Yes Yes Yes
Example: The version number of the system software is version
4.38.
LSD240=0438(Hex), LSD241=0000(Hex)
LSD242, 243
Version number of WindO/I-NV4
Yes Yes Yes YesExample: The version number of WindO/I-NV4 is version 1.2.3.
LSD242=0102(Hex), LSD243=0300(Hex)
LSD244 to 247 Reserved
LSD248
File transfer status to the USB flash drive by using the FTP server
function.
The following bit changes to 1 while transferring files to USB flash
drive inserted into the MICRO/I from an FTP client.
The bit changes to 0 after the transfer.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 8: Sound file
*9
Bit 9: ZLD Project File
Bit 10: Movie file
*11
Bit 15: Other file
No Yes Yes Yes
LSD249
File transfer status to the SD memory card by using the FTP server
function.
The following bit changes to 1 while transferring files to SD memory
card inserted into the MICRO/I from an FTP client.
The bit changes to 0 after the transfer.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 8: Sound file
*9
Bit 9: ZLD Project File
Bit 10: Movie file
*11
Bit 15: Other file
No Yes Yes No
LSD250 to 255 Reserved
LSD256
Input mode of Character Input
Stores the input method from the keypad for the Character Input.
0: Direct input mode
1: Kanji input mode
No Yes No No
LSD257 to 259 Reserved
LSD260
BACnet communication status
Stores the status for BACnet communication.
Bit 0: Stopped
Bit 1: Ready
Bit 2: Operating
Bit 3: Stopped by error
No Yes No No
LSD261
BACnet Communication Error Information
Stores the last error information that has occurred in BACnet
communication.
Bit 0: Normal
Bit 1: Invalid device ID
Bit 2: Invalid IP address
Bit 3: Invalid BBMD IP address
Bit 4: BBDM registration failure
No Yes No No
LSD262 to 269 Reserved
