WindO/I-NV4 User’s Manual 3-125
7 BACnet Communication
3
Communication
● Analog Input Object
This object manages a Float32(F) numeric value. The MICRO/I can make arbitrary numeric values available to BACnet
devices. For example, use this object when handling analog values input with the analog input module, the measured
room temperature, and other analog values.
Properties List
(1): Read and write from BACnet devices
(2): Read and write from device addresses when properties are allocated to device addresses
R: Read-only, W: Write-only, R/W: Read and write, -: Not Read and write
*1 Character encoding is ISO 10646 (UTF-8), and the maximum size is 64 bytes.
*2 Cannot be displayed on WindO/I-NV4.
Property Identifier Data Type of Property (1) (2) Comments
Object_Identifier BACnetObjectIdentifier R - Set a fixed value with WindO/I-NV4.
Object_Name
Character string
*1
R - Set a fixed value with WindO/I-NV4.
Object_Type BACnetObjectType R - Set a fixed value with WindO/I-NV4.
Present_Value Real number R W Refer to “Present_Value” on page 3-132.
Description
Character string
*1
R - Set a fixed value with WindO/I-NV4.
Device_Type
Character string
*1
R - Set a fixed value with WindO/I-NV4.
Status_Flags BACnetStatus_Flags R R Refer to “Status_Flags” on page 3-145.
Event_State BACnetEventState R - Normal (fixed).
Reliability BACnetReliability R R/W
Indicates whether or not the value of
Present_Value is reliable.
Out_Of_Service Logical value R/W R/W Refer to “Out_Of_Service” on page 3-146.
Units BACnetEngineeringUnits R/W - Set the initial value with WindO/I-NV4.
Resolution Real number R - Set a fixed value with WindO/I-NV4.
COV_Increment Real number R/W - Refer to “COV_Increment” on page 3-145.
Property_List
*2
BACnetARRAY[N] of type
BACnetPropertyIdentifier
R - Cannot be edited with WindO/I-NV4.
To Next Page
