3 Project Settings Dialog Box
4-46 WindO/I-NV4 User’s Manual
When USB1(USB-B) or USB(USB-B) is selected under Interface Configuration
The items displayed in the Interface vary based on the MICRO/I model.
■ Default
Returns the configured values to their default values.
*7 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
• Check the IDEC web site for more information about compatible wireless LAN adapter.
• The wireless LAN network settings and connection status can be checked and controlled with the value of
the HMI Special Data Registers (LSD) and HMI Special Internal Relays (LSM).
LSD292 to 341: SSID and password of the access point
LSD344 to 351: IP address and subnet mask of the wireless LAN
LSD356: Port number for maintenance communication on the wireless LAN
LSD366: Wireless LAN connection status
LSD367: Wireless LAN signal strength
LSM77: Writing the wireless LAN network settings
LSM78: Connecting and disconnecting from the wireless LAN
For details, refer to Chapter 33 “Internal Devices” on page 33-1.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F, HG1G/1P: USB1(USB-B)
HG2G-5T: USB(USB-B)
Function:
Selects the function used by the USB interface (Mini-B) as N/A or Printer.
*7
