WindO/I-NV4 User’s Manual 8-97
5 Key Button
8
Buttons
● For Data Transfer Keys
These keys can be used to execute Data Transfer functions. For details about Data Transfer functions, refer to Chapter
29 “Data Transfer Function” on page 29-1.
●
For Alarm Displays
These keys can be used for the Alarm List Display and Alarm Log Display parts.
■ Alarm List Display
■ Alarm Log Display
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
Key Operation
Download Project Downloads a project (ZNV Project File) saved on an external memory device to the MICRO/I.
Upload Project
Uploads the project used for operation on the MICRO/I and saves the ZNV Project File(.znv) to
an external memory device.
Copy Files
*1
Copy files between and within external memory inserted in MICRO/I.
Download PLC Program
Downloads a PLC program (ZLD Project File) saved on an external memory device to a PLC
connected to the MICRO/I.
Upload PLC Program
Uploads a PLC program from the PLC connected to the MICRO/I and saves the ZLD Project
File(.zld) to an external memory device.
Key Operation
Page Up Scrolls up the number of lines (1 to 1023) specified in Scroll Size.
Page Down Scrolls down the number of lines (1 to 1023) specified in Scroll Size.
Up
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing Select.
Down
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing Select.
Select Toggles the focus between show and hide.
Reference The reference screen appears.
Press and hold the Page Up, Page Down, < Cur., and Cur. > keys for more than one second to move the
focus repeatedly.
Key Operation
Up
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing Select.
Down
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing Select.
Select Toggles the focus between show and hide.
Check Shows the date and time the alarm that has focus was confirmed.
All Check Shows the date and time that all alarms were confirmed.
Delete Clears the alarm that has focus.
Delete All Clears all alarms.
Reference Shows the reference screen for the alarm that has focus.
Stop Buzzer and Screen
Flashing
Stops the sound of the buzzer and screen flashing when an alarm occurs.
Press and hold the Up and Down keys for more than one second to move the focus repeatedly.
