WindO/I-NV4 User’s Manual 10-103
5 Message Display
10
Data Displays
● Format Tab
■ Font
Selects the font used for displaying text from the following.
Western, Japanese, Simplified Chinese, Traditional Chinese, Hangul, Central European, Baltic, Cyrillic,
Stroke
*1
The characters that can be displayed depend on the font. For details, refer to Chapter 2 “1.2 Available Text” on page
2-6.
■ Size
Specifies the text size to be displayed. The fonts and sizes that can be set vary based on the model.
■ Style
*1
Selects Regular or Bold for text style.
Can only be set when Western, Japanese, Simplified Chinese, Traditional Chinese, Hangul, Central
European, Baltic, Cyrillic is selected for Font.
■ Magnification
*1
Can only be set when Western, Japanese, Simplified Chinese, Traditional Chinese, Hangul, Central
European, Baltic, Cyrillic is selected for Font.
■ Align Text Horizontal
Selects the text alignment in the horizontal direction from the following.
Left, Center, Right, Center-Left, Left-Right
If Top, Center or Bottom is selected for Align Text Vertical, Center or Right can be set as this option.
If Center-Top is selected for Align Text Vertical, Center-Left or Left-Right can be set as this option.
For details, refer to Appendix “5 Text Alignment” on page A-7.
■ Align Text Vertical
Selects the text alignment in the vertical direction from the following.
Top, Center, Bottom, Center-Top
Set to Center when the Vertical Writing check box is selected.
For details, refer to Appendix “5 Text Alignment” on page A-7.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
Model Font Size
HG2J-7U
Western, Japanese, Simplified Chinese, Traditional Chinese, Hangul,
Central European, Baltic, Cyrillic
8 to 150
HG5G/4G/3G/2G-V, HG4G/3G,
HG2G-5F/-5T, HG1G/1P
Stroke 8 to 128
W, H: Selects text magnification (0.5, 1 to 8).
