WindO/I-NV4 User’s Manual 10-105
5 Message Display
10
Data Displays
â– Scroll
*2
Select this check box to enable scrolling display displaying of messages.
This option can only be configured when the Flash check box is cleared and Standard is selected for Image Type
on the View tab.
*2 Advanced mode only
Speed (1: Fastest): Sets the scrolling speed (1 to 10). 1 is fastest, 10 is slowest.
Start scrolling after displaying message: Select this check box to start scrolling after a message is displayed for 2
seconds.
This check box is cleared. This check box is selected.
After 2 seconds,
start scrolling it.
Start scrolling
a message.
Display a message
and align left.
Voltage abnormal
V
Vo oltage abnormal
Vol ltage abnormal
• When the Scroll check box is selected, the number of parts that can be arranged on a single screen
decreases. If the MICRO/I displays an error message, clear the Scroll check box, or reduce the number
of parts on the screen.
• When the scan time for the screen becomes longer, and when the part that has its Scroll check box
selected is placed on the top layer, the scrolling speed may become slow.
When the Scroll check box is selected operation is follows.
• Messages that include CRs are displayed without the CRs.
• Messages scroll in the direction in which the text is drawn.
• When the text displayed according to values of device addresses, the text color, or the displayed text
changes, the message is scrolled top the beginning.
