5 Message Display
10-110 WindO/I-NV4 User’s Manual
Trigger Condition Tab
The Trigger Condition tab is displayed in Advanced mode.
The Message Display is enabled while the condition is satisfied, and it is disabled while the condition is not satisfied.
Select the operation when disabled as Not display message or Not show Message Display under While not
satisfying the condition.
Trigger Type
Selects the condition to enable the Message Display from the following.
Example: When Trigger Type is While ON, Device Address is LM0, and While not satisfying the condition is
Not display message.
While LM0 is 0, the condition is not satisfied and the Message Display does not display the message.
While LM0 is 1, the condition is satisfied and the Message Display displays the message.
LM0
:
MICRO/I
0
LM0
:
1
HG SERIES
Condition
Not
satisfied
Condition
Satisfied
Show
Hide
Always visible: The Message Display is always enabled.
Message Display
state
Always show message
HG SERIES
