7 Alarm List Display
10-146 WindO/I-NV4 User’s Manual
Set with Dots: Specifies the line spacing for the message to display for one alarm line in dots.
Enter the height (8 to (base screen vertical size -3)). The range that can be specified varies based on
the vertical size of the base screen and the character height.
The character height setting varies based on the model.
HG2J-7U: Size is 16.
To display a one-line message, 1 x 24 = 24 dots, a line spacing of 24 dots or higher is required.
To display a two-line message, 2 x 24 = 48 dots, a height of 48 dots or higher is required.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: Magnification H is 1.
To display a one-line message, 1 x 16 x 1 = 16 dots, a line spacing of 16 dots or higher is required.
To display a two-line message, 1 x 16 x 2 = 32 dots, a line spacing of 32 dots or higher is required.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: Magnification H is 2.
To display a one-line message, 2 x 16 x 1 = 32 dots, a line spacing of 32 dots or higher is required.
To display a two-line message, 2 x 16 x 2 = 64 dots, a line spacing of 64 dots or higher is required.
24 dots
Line Spacing
Current fault has occurred
Pump fault has occurred
Line Spacing
Line Spacing
24 dots
48 dots
Current fault
has occurred
has occurred
Pump fault
Current fault
Pump fault
When the message is 2 lines,
2nd line is not shown.
16 dots
Current fault has occurred
Pump fault has occurred
Line Spacing
16 dots
32 dots
Current fault
has occurred
has occurred
Pump fault
Current fault
Pump fault
Line Spacing Line Spacing
When the message is 2 lines,
2nd line is not shown.
Line Spacing
32 dots
Current fault has occurred
Pump fault has occurred
Line Spacing
32 dots
Current fault Current fault
Pump fault
Pump fault
Line Spacing
64 dots
has occurred
has occurred
When the message is 2 lines,
2nd line is not shown.
