WindO/I-NV4 User’s Manual 10-147
7 Alarm List Display
10
Data Displays
■ Scroll
*3
Select this check box to enable scrolling display displaying of messages.
Can only be set when One Line is selected for Display Type under the General tab.
For Alarm List Display, this can only be set if One Line is selected for Display Type under the General tab.
*3 Advanced mode only
Speed (1: Fastest): Sets the scrolling speed (1 to 10). 1 is fastest, 10 is slowest.
Start scrolling after displaying message: Select this check box to start scrolling after a message is displayed for 2
seconds.
Page
Up
Page
Down
Vo
Page
Up
Page
Down
Vol
This check box is cleared. This check box is selected.
After 2 seconds,
start scrolling it.
Start scrolling
a message.
Display a message
and align left.
Page
Up
Page
Down
Page
Up
Page
Down
Voltage abnormal
Page
Up
Page
Down
V
Page
Up
Page
Down
oltage abnormal
Page
Up
Page
Down
ltage abnormal
• When the Scroll check box is selected, the number of parts that can be arranged on a single screen
decreases. If the MICRO/I displays an error message, clear the Scroll check box, or reduce the number
of parts on the screen.
• When the scan time for the screen becomes longer, and when the part that has its Scroll check box
selected is placed on the top layer, the scrolling speed may become slow.
When the Scroll check box is selected operation is follows.
• Messages that include CRs are displayed without the CRs.
• Messages scroll in the direction in which the text is drawn.
• When the text displayed according to values of device addresses, the text color, the displayed text, or the
alarm state changes, the message is scrolled from the beginning.
