4 Customizing WindO/I-NV4
2-64 WindO/I-NV4 User’s Manual
■ Color LCD models, Monochrome LCD models
Screen Background
Color:
The background color of the base screen, popup screen, and password input screen
specified here becomes the default.
Part Properties: The properties of the part specified here becomes the default.
To set the shape to be used for the appearance design of the part, click the Shape button.
The View Browser is displayed. For details on other settings, refer to the description of the
properties of each part. The part properties that can be set are as follows.
Parts Settings
Buttons
Bit Button
Word Button
Goto Screen Button
Print Button
Key Button
Multi-Button
View tab
The shape used for the appearance design of the part
Foreground Color, Background Color and Pattern when OFF
Foreground Color, Background Color, Pattern and Flash when ON
Size - W, H
Registration
Text tab
Font
Keypad -
The shape used for the appearance design of the part
Switch - Foreground Color, Background Color and Pattern
Registration Text - Font
Size - W, H
Selector Switch
View tab
Knob Color
Flange - Foreground Color, Background Color and Pattern
Switch - Foreground Color, Background Color and Pattern
Size - W, H
Registration
Text tab
Font
Potentiometer View tab
The shape used for the appearance design of the part
Slider Color
Plate Color
Flange - Foreground Color, Background Color and Pattern
Switch - Foreground Color, Background Color and Pattern
Size - W, H
Lamps
Pilot Lamp
View tab
The shape used for the appearance design of the part
Foreground Color, Background Color, Pattern and Not Display
Image when OFF
Foreground Color, Background Color and Pattern when ON
Size - W, H
Registration
Text tab
Font
Multi-State Lamp
View tab
Size - W, H
Registration
Text tab
Font
State tab
OFF state and state 0 to 15 of Settings - Image, Foreground Color,
Background Color, Pattern and Flash
Data
Displays
Numerical Input
Character Input
Message Display
Message Switching
Display
Numerical Display
Calendar
View tab
The shape used for the appearance design of the part
Plate Color
Flange - Foreground Color, Background Color and Pattern
Size - W, H
Format tab
Font
Picture Display View tab
Size - W, H
Video Display View tab
The shape used for the appearance design of the part
Plate Color
Flange - Foreground Color, Background Color and Pattern
Switch - Foreground Color, Background Color and Pattern
Size - W, H
