6 Multi-Command
12-46 WindO/I-NV4 User’s Manual
■ Goto Screen
*1 This is applicable for models with a video interface only.
*2 Advanced mode only
Screen Number: If Action Mode is set to Switch to Base Screen, specify the Base Screen number to switch to
(from 1 to 3000). If Action Mode is set to Open Popup Screen or Close Popup Screen,
specify the number of the Popup Screen to open or close (from 1 to 3015).
This setting is enabled only if Action Mode is set to Switch to Base Screen, Open Popup
Screen, or Close Popup Screen.
Use Reference Device Address
*2
:
Select this check box and specify a device address to specify
the screen number using the value of the specified device
address.
Click to display the Tag Editor. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
This setting is enabled only if Action Mode is set to Open
Popup Screen or Close Popup Screen.
Coordinates X, Y: Specify the coordinates on the Base Screen for displaying a window.
X and Y specify the upper left corner of the window using the upper left corner of the screen as
the origin.
This setting is enabled only if Action Mode is set to Open Popup Screen, Open Device
Monitor Screen, Open Password Screen, Open Adjust Brightness Screen, or Open File
Screen for Movie Files
*1
.
Use Reference Device Address
*2
:
Select this check box and specify a device address to specify
the coordinates using the value of the specified device address.
Click to display the Tag Editor. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
This setting is enabled only if Action Mode is set to Open
Popup Screen.
To Next Page
