5.1.3.1.2.1 Resetting of summation
With the measurement modes involving summation (events, angle and displacement), it is possible to
reset the sum to zero during a running measurement. This can be accomplished in either of two ways:
Measure dialog: The reset command from the channel menu is used to manually reset all selected
incremental counter channels.
Special Functions node: On the Resetting page, it is possible to enable separate resetting of each
channel by means of a CAN-Bus message.
Manual resetting by means of Measure dialog
Manual resetting of summation by means of
Measure dialog
Resetting the summation by means of a CAN-bus message
INC Special functions: Resetting of summation
This dialog enables resetting of the summations of individual incremental counter channels.
