464 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value (typ. / max)
Remarks
<0.05 %
<0.15 %
<0.15 %
with voltage plug
with divider plug
shunt plug
Gain drift
<75 ppm / K
Offset
<0.02 %
throughout entire temperature range
Temperature uncertainty
< 1 K
sensor: type K at 20°C
throughout entire temperature range
Noise
50 V pp
25 mV pp
7 V rms
7 mV rms
range ±100 mV, RSource = 50 ,
sampling rate 2 ms
range ±10 V (divider)
CMRR / IMR
>100 dB (50 Hz)
common-mode reference: enclosure
(CHASSIS)
all other channels: CHASSIS
Supply voltage
9 V to 32 V DC
Power consumption
<2.5 W (typ.)
<3.0 W (max.)
12 V, throughout entire temperature
range
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
75 x 111 x 145 mm
40 x 128 x 145 mm
CANSAS-C12
CANSAS-L-C12-T
CANSAS-K-C12 (8 TE Cassette)
Weight
300 g
Module description C12
