Temperature measurement
Parameter
Value typ.
min. / max.
Remarks
Signal-noise ratio
>85 dB
bandwidth 10 Hz
Bandwidth
0 Hz to 10 Hz
-3 dB
Thermocouples
Input ranges
J, T, K, E, N, S, R, B
per IEC 584
Resolution
0.025 K
0.0031 K
type K
-270°C to 1370°C
-50°C to 150°C
Uncertainty thermocouples
0.2K
< 0.5 K
Types J, T, K, E, L
(for all other types, the voltage
measurement uncertainty applies)
drift
0.02 K/K T
a
T
a
= |T
a
-25°C|
ambient temperature T
a
Uncertainty of cold junction
compensation
< 0.15 K
< 0.5 K
CAN-C8-DSUB (standard)
CAN-L-C8-2T
Drift of cold junction
0.001 K/K T
j
T
j
= |T
j
-25°C| ; could junction T
j
Input impedance
100 k
differential
RTD (Pt100)
Input range
-200°C to 850°C, -50°C to 150°C
0.016 K, 0.003 K (resolution)
Uncertainty
< 0.2 K
< 0.1 K
< 0.05%
-200°C to 850°C, four-wire connection
-50°C to 150°C, four-wire connection
plus of range
Drift
0.01 K/K T
a
T
a
=|T
a
-25°C| ambient temperature T
a
Pt100 sensor feed
625 µA
Input impedance
20.0 M
1%
differential
Power supply of the module
Parameter
Value
Remarks
Supply voltage
10 V to 50 V DC
Power consumption
<2.5 W
Sensor supply
2.5 V to 24 V
technical specs sensor supply
Operating temperature
<%TEMPERATURE_M40%>
Dimensions (W x H x D)
35 x 111 x 90 mm
75 x 111 x 145 mm
41 x 128 x 145 mm
81 x 128 x 145 mm
58 x 112.5 x 152 mm
38 x 112.5 x 152 mm
78 x 112.5 x 152 mm
58 x 112.5 x 152 mm
CANSAS-C8
CANSAS-L-C8, -L-C8-SUPPLY
CANSAS-K-C8 (8 HP cassette)
CANSAS-K-C8-BNC, -K-C8-2T
CANSAS-K-C8-SUPPLY
CANSAS-SL-C8-L
CANSAS-SL-C8-D
CANSAS-SL-C8-L-SUPPLY
CANSAS-SL-C8-D-SUPPLY
