494 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
CANSAS-IP65-P8 fluid pressure measurement module
Channel
Range
Medium
Sensor
Module nipple
Recommended coupling (optional)
1, 2
0..10bar
fuel
absolute
pressure
sensor (A10)
NW5, chrome-plated brass,
Kalrez
®
-sealing, leakage-
free
order code: CAN/21KLAD14MKC
NW5, chrome-plated brass, Kalrez®-
sealing, leakage-free
3,4,5
0..6bar
oil /
water
absolute
pressure
sensor (A10)
NW7,8, stainless, Viton
®
-
sealing, free passage
CAN/25KAAD14RVX
NW5, stainless, Viton®-sealing, one-
way flow
6,7,8
0..10bar
oil /
water
absolute
pressure
sensor (A10)
NW5, stainless, Viton
®
-
sealing, free passage
CAN/25KAAD14RVX
NW5, stainless, Viton®-sealing, one-
way flow
1
Due to the effect of gravity on the oil column in its internal barometer, the sensors' high sensitivity can lead to
offset errors if its position is changed. (For measurements of relative pressure, this can be compensated using the
Tare function)
3
Leak-free signifies that the nipples come with a valve which closes automatically when the tube is disconnected
(useful for liquids).
4 Brand name: Kalrez®
5
Brand names: Viton®, Technoflon®, Fluorel®,
6
Brand names: Perbunan® , Chemigum®, Hycar®, Krynac®, Elaprim®, JSR-N®
CANSAS-L-P8-G4 gas pressure measurement module, Type IV
Channel
Range
Medium
Sensor
Module nipple
Recommended coupling (optional)
1-8
0..10bar
Gas
absolute
pressure
sensor (A10)
NW5, brass, Perbunan®-
sealing, free passage
CAN/21KFAD14MPX: NW5, brass,
Perbunan®-sealing, free passage
