General technical specs
Parameter
Value (typ. / max.)
Remarks
Isolation:
CAN-Bus
±50 V
to housing (CHASSIS)
Supply voltage
10 V to 50 V DC
Power consumption:
5 W (typ.)
8 W (max.)
24 V, over entire temperature range
Operating temperature
-15°C to 60°C
ambient temperature
Shock resistance
50 g pk
over 5 ms
Dimensions (W x H x D)
111 x 115 x 145 mm
122 x 128 x 145 mm
129 x 110 x 188 mm
CANSAS-L-P8 (dimensions without
terminals)
CANSAS-K-P8
CANSAS-IP65-P8 (incl. mounting angle)
Weight
approx. 1.3 kg
approx. 1.8 kg
CANSAS-L-P8
CANSAS-IP65-P8
Connection terminals
8 x pressure nipples
2x DSUB-9
PHOENIX (MC 1.5/4STF-3.81)
AMPHENO (C091 4-pin M)
AMPHENO (C091 3-pin M)
Inputs:
CANSAS-L-P8
CAN (in / out)
Supply
CANSAS-IP65-P8
CAN (in / out)
Supply
Remarks:
Accuracy ratings pertain to state after transients.
If the module is subjected to accelerations, the inertia will cause measurement errors with the
sensitive sensors.
