532 Pin configuration and power supply
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Order code: CAN/µ-CAN-F-CON Art. # M. 1160021
Connector with cable socket; 6-pin female AS608-35SA for the CAN-terminal of imc µ-CANSAS-x1-AS(T)
and for the male CAN-connection of imc µ-CANSAS-x4-AS and µ-HUB4-AS (if connected at CAN IN socket
[right side])
Order code: CAN/µ-CAN-M-CON Art. # M. 1160022
Connector with cable socket; 6-pin male AS608-35PA for the female CAN-terminal of imc µ-CANSAS-x4-
AS, µHUB4-AS (if connected at CAN OUT [left side]) and for the four IN terminals of µ-HUB4-AS.
Order code: CAN/µ-CABLE-MODT Art. # M. 1160023
CAN connector cable, shielded, 1,5 m, 6-pin female AS608-35SA to 6-pin male AS608-35PA, with built-in
terminator resistor on module side. Temperature range: -15 °C … 60 °C. For connection of a µimc
CANSAS-x1-AS with a µ-HUB4-AS
Order code: CAN/µ-CABLE-1-HT Art. # M. 1160024
Type 1 CAN connection cable: From 6-pin female AS608-35SA on device side to 9-pin DSUB-socket;
shielded, 1,5 m. Temperature range: -40 °C … 120 °C. For direct connection of imc µ-CANSAS-x1-AST, imc
µ-CANSAS-x4-AS(T) and µ-HUB4-AS (imc µ-CANSAS connected via male CAN-terminal, if connected at
CAN IN socket [right side]) to the imc CAN-interface, if the module is supplied via the CAN-Bus.
Order code: CAN/µ-CABLE-MODT-HT Art. # M. 1160025
CAN connection cable, shielded, 1,5 m, 6-pin female AS608-35SA to 6-pin male AS608-35PA, with built-in
terminator resistor on the module side. Temperature range: -40 °C … 120 °C. For connecting a imc µ-
CANSAS-x1-AS with a µ-HUB4-AS.
Order code: CAN/µ-CABLE-MOD-HT Art. # M. 1160026
CAN connection cable, shielded, 1,5 m, 6-pin female AS608-35SA to 6-pin male AS608-35PA.
Temperature range: -40 °C … 120 °C. For connecting a imc µ-CANSAS-x1-AST or imc µ-CANSAS-x4-AS with
a µ-HUB4-AS, or a µ-HUB4-AS together with a imc µ-CANSAS-x4-AS.
Order code: CAN/µ-Y-CABLE Art. # M. 1160027
CAN-Bus Y-cable; 6-pin female AS608-35SA on device side to 9-pin DSUB-socket and 9-pin DSUB-plug,
shielded. Temperature range: -40 °C … 120 °C. For connecting multiple imc µ-CANSAS-x1-AS(T) units
together or connection to the imc CAN-interface, if the module is supplied via the CAN-Bus. Due to the
0,14 mm² wire cross-section, only partially suitable for power supply via CAN-Bus.
Order code: CAN/µ-Y-CABLE-HT Art. # M. 1160028
CAN-Bus Y-cable, 6-pin female AS608-35SA on device side to 9-pin DSUB-socket and 9-pin DSUB-plug,
shielded. Temperature range: -15 °C … 60 °C. For connection of multiple imc µ-CANSAS-x1-AS(T) units
together or connection to the imc CAN-Interface if the module is supplied via the CAN-Bus. Due to the
0,14 mm² wire cross-section, only partially suitable for power supply via CAN-Bus.
Order code: CAN/µ-CABLE-CONFIG Art. # M. 1160029
Configuration cable for imc µ-CANSAS-xx-AS(T), 6-pin female AS608-35SA on device side to 9-pin DSUB-
socket, 9-pin DSUB-plug and 4-pin Phoenix socket, shielded. Temperature range: -15 °C … 60 °C.
Connection to µimc CANSAS via the male CAN-terminal (if connected at CAN IN [right side]); power
supply via 4-pin Phoenix socket. Connection to imc CAN-interface via either the DSUB-socket or DSUB-
plug. Due to the 0,14 mm² wire cross-section, only partially suitable for power supply via CAN-Bus.
