Diagnostic information 2-43
7510
200.03 Sensor (media on belt) late jam
4
POR the machine.
Does the error continue?
Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-91.
Problem solved.
Step Check Yes No
1 Check the media condition.
Is the media in the tray crumpled, curled or damaged?
Replace the
damaged media
with new.
Go to step 2.
2
Check the media position.
Does the media touch the sensor (media on belt)?
Remove the
media.
Go to step 3.
3
Check the 2nd transfer roll assembly for excess wear or
damage.
Is the above component free of excess wear and damage?
Go to step 4. Replace the 2nd
transfer roll
assembly.
Go to “2nd
transfer roll
assembly
removal” on
page 4-45.
4
Check the sensor (media on belt) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch BASE SENSOR TEST.
3. Touch Media Path.
4. Touch Media on belt.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
5
Check the sensor (media on belt) for proper connection.
Is the above component properly connected?
Replace the
sensor (media on
belt).
Go to “Sensor
(media on belt)
removal” on
page 4-40.
Replace the
connection.
6
Perform a print test.
Does the error continue?
Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-91.
Problem solved.
Step Check Yes No
