295.03 Too short size jam
8
Check the sensor (ADF width APS 3) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 3.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 10. Go to step 9.
9
Check the sensor (ADF width APS 3) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
width APS 3).
Go to “Sensor
(ADF width
APS 3)
removal” on
page 4-155.
Replace the
connection.
10
Perform a POR.
Does the error remain when the power is turned off/on?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 11.
Problem solved.
11
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
Step Check Yes No
1 Check the document size.
Is the correct size document being inserted into the ADF?
Go to step 2. Insert the proper
size document into
the ADF.
2
Check the sensor (sheet through) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch Sheet through.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
Step Check Yes No
