Lexmark X945e MFP 7510 series - Assembly 28: Cooling Fans

7-30 MFP Service Manual
7510
Go Back
Previous
Next
Assembly 28: Cooling fans
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X3750 1 1 Fuser cooling fan
2 40X3749 1 1 Printhead shutter motor assembly
3 40X3752 1 1 Rear lower cooling fan assembly (this comes assembled)
4 40X3751 1 1 Transfer belt drive motor cooling fan
3
2
4
1
