Diagnostic information 2-105
7510
295.02 Invalid combine size jam
Step Check Yes No
1 Check the document size.
Is the correct size document being inserted into the ADF?
Go to step 2. Insert the proper
size document into
the ADF.
2
Check the document tray media guide position.
Are the document tray media guides set correctly?
Go to step 3. Adjust the
document tray
media guides to
the proper position.
3
Check the connection of each ADF controller card assembly
connector.
Is each connector of ADF controller card assembly
connected properly?
Go to step 4. Connect each
connector of ADF
controller card
assembly properly.
4
Check the sensor (ADF width APS 1) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 1.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
5
Check the sensor (ADF width APS 1) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
width APS 1).
Go to “Sensor
(ADF width
APS 1)
removal” on
page 4-153.
Replace the
connection.
6
Check the sensor (ADF width APS 2) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 2.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 8. Go to step 7.
7
Check the sensor (ADF width APS 2) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
width APS 2).
Go to “Sensor
(ADF width
APS 2)
removal” on
page 4-154.
Replace the
connection.
To Next Page
