Diagnostic information 2-187
7510
942.00 Switch (media size) size sensing error (tray 2)
4
Check the media feed/lift motor (tray 1) for proper
operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Tray 1 media feed/lift motor.
Warning: The media tray must be opened before performing
this test or paper jam may occur.
Does the above component operate properly?
Go to step 6. Go to step 5.
5
Check the media feed/lift motor (tray 1) for proper
connection.
Is the above component properly connected?
Replace the media
feed/lift motor.
Go to “Media feed
lift motor
removal” on
page 4-120.
Replace the
connection.
6
Perform a POR.
Does the error continue when the power is turned off/on?
Replace the upper
printer engine card
assembly.
Go to “Upper
printer engine
card assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Check the media.
Is media loaded in tray 2 properly?
Go to step 2. Load media
properly.
2
Check the media tray.
Are the size sensing mechanisms on the back and the
bottom of the media tray damaged.
Replace the media
tray assembly.
Go to step 3.
3
Check the tray 2 switch (media size) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor Test.
4. Touch Tray 2.
5. Touch Tray 2 present.
Does the display on the operator panel, change every time
the media tray is opened and closed?
Go to step 5. Go to step 4.
Step Check Yes No
To Next Page
