1-42 Service Manual
7510
Go Back
Previous
Next
Drive torque transfer scheme
ADF feed motor assembly
The rotational force of the ADF feed motor assembly is transferred to each document feeding roll as shown
below.
ADF registration motor
The rotational force of the ADF registration motor is transferred to each document feeding roll as shown below.
ADF feed motor assembly
ADF drive belt
Feed drive rear pulley 14/32/37
Transport roll drive belt
Feed/pick drive gear 20T
Transport roll drive
gear/pulley 20/50T
Feed/pick drive
shaft assembly
Transport roll drive gear 20T
Feed roll drive gear 26T
Transport roll assembly
Feed roll Pick roll idler gear 36T
Pick roll drive gear 34T
Pick roll
