4-6 Service Manual
7510
Go Back
Previous
Next
Rear left middle cover removal
1. Remove the rear cover assembly. See “Rear cover assembly removal” on page 4-5.
2. Open the printer left door assembly.
3. Remove the screw securing the rear left middle cover (A) to the machine.
4. Remove the rear left middle cover.
A
