Lexmark X945e MFP 7510 series User Manual

Diagnostic information 2-179
7510
Go Back
Previous
Next
924.01 Magenta PC smartchip communication error
4
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for wear or damage.
Is the above component free from damage?
Go to step 5. Replace the
developer
interlock plate
assembly.Go to
“Developer
interlock plate
assembly
removal” on
page 4-59.
5
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the upper
printer engine card
assembly. Go to
“Upper printer
engine card
assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Check the M PC cartridge for proper installation.
Is the above component properly installed?
Go to step 2. Reinstall the M PC
drum.
2
Install the M PC drum in one of the other three PC locations.
Ensure that all PC drum slots contain a PC drum. Perform a
POR.
Does the error remain or follow the problematic cartridge?
Replace the
problematic PC
drum with a new
one.
Go to step 3.
3
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for proper connection.
is the above component properly connected?
Go to Step 4 Replace the
connection.
4
Check the appropriate smartchip socket, located on the
developer interlock plate assembly for wear or damage.
Is the above component free from damage?
Go to step 5. Replace the
developer
interlock plate
assembly. Go to
“Developer
interlock plate
assembly
removal” on
page 4-59.
5
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the upper
printer engine card
assembly. Go to
“Upper printer
engine card
assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
