7-12 MFP Service Manual
7510
Go Back
Previous
Next
Assembly 10: MPF feed unit assembly 2
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X4079 1 1 MPF feed unit assembly (this comes assembled)
2 40X3688 30 1 Sensor (MPF media out)
3 40X3709 1 1 MPF media out actuator
4 40X0755 1 1 MPF pickup spring
