Gear layout
ADF registration motor
Registration roll drive belt
Registration drive
gear/pulley 21/54T
Registration drive belt
Exit/feed-out drive
pulley 25/28
Registration roll
drive gear 28T
Exit roll drive belt
Feed-out roll assembly
Registration roll assembly
Exit roll drive pulley 20T
Exit roll assembly
