Diagnostic information 2-125
7510
845.01 CCD initialization (lamp on) error
3
Perform a POR.
Does the error remain?
Replace the
scanner
controller card
assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-130.
Step Check Yes No
1 Check the exposure lamp for operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Exposure lamp.
Does the exposure lamp operate properly?
Go to step 6. Go to step 3.
2
Check the exposure lamp for connection.
Is the above component properly connected?
Replace the
exposure lamp.
Go to “Exposure
lamp removal”
on page 4-129.
Replace the
connection.
3
Check the exposure lamp PS card assembly.
Is the above card properly connected to the scanner
controller card assembly?
Replace the
exposure lamp
PS card
assembly.
“Exposure lamp
PS card
assembly
removal” on
page 4-129.
Replace the
connection.
4
Check the scanner PS card assembly for connection.
Is the above card connected properly?
Replace the
scanner PS card
assembly.
Go to “Scanner
PS card
assembly
removal” on
page 4-133.
Replace the
connection.
Step Check Yes No
To Next Page
