7-16
MFP Serv
ice Manual
7510
Go B
ac
k
Previous
Next
Assem
b
ly 1
4: P
rint
er le
ft
do
or
ass
emb
ly
1
Asm-
index
Part
number
FRUs/
mac
h
Units/
FRU
Descri
ption
1
40X4078
1
1
Printer lef
t door asse
m
bly
(thi
s comes assembl
ed)
2
40X3699
1
1
Sensor (
fuser
exit)
3
40X4098
1
1
Printer lef
t door closed
actuator
4
40X3698
1
1
2nd transf
er roll assembl
y
5
40X3700
1
1
Printer lef
t door duplex exi
t guide
749
751
