Diagnostic information 2-95
7510
292.01 ADF raised jam
292.02 ADF left cover jam
293.00 Document missing jam
13
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 14.
Problem solved.
14
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
Step Check Yes No
1 Remove all documents from the ADF.
Does the error remain?
Perform a POR. Problem solved.
Step Check Yes No
1 Remove all documents from the ADF.
Does the error remain?
Perform a POR. Problem solved.
Step Check Yes No
1 Check the original document condition.
Is the original document free of paper clips and staples as
well as damage such as creases, tears, holes or excessive
wear?
Go to step 2. Remove damaged
original document
and replace with a
new undamaged
original document.
Perform a ADF
test. If the problem
remains, go to
step 2.
Step Check Yes No
