Diagnostic aids 3-51
7510
Go Back
Previous
Next
Repeating defects
Roll Pitch
2nd transfer roll 83.05 mm
Registration roll 62.61 mm
Developer magnetic roll 33.76 mm
Developer auger roll 43.89 mm
Fuser hot roll 85.15 mm
Charge roll 43.98 mm
PC drum 94.25 mm
Transfer belt 949.00 mm
Fuser
pressure roll
Fuser hot roll
2nd transfer roll
Registration roll
PC drum
Charge roll
