Control sensor check
Control sensor cycle
Step Check Yes No
1 Perform the Control sensor check test.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Control Sensor Check
Does the above test pass?
Perform the
“Control sensor
cycle”.
See “Control
sensor cycle” on
page 4-266.
Go to step 2.
2
Check the transfer belt unit assembly for damage.
Does above component show signs of damage on the
frame or on the belt?
Replace the
transfer belt unit
assembly.
See “Transfer
belt unit
assembly
removal” on
page 4-16.
Go to step 3.
3
Re-perform the Control sensor check test again.
Does the above test pass?
Perform the
“Control sensor
cycle”.
See “Control
sensor cycle” on
page 4-266.
Contact next level
of support.
Step Check Yes No
1 Perform the Control sensor cycle test.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Control Sensor Cycle
Does the above test pass?
Perform the “Belt
edge learn test”.
See “Belt edge
learn test” on
page 4-267.
Go to step 2.
2
Check the upper printer engine card assembly connections.
Is the above component properly connected?
Replace the upper
printer engine card
assembly.
See “Upper
printer engine
card assembly
removal” on
page 4-88.
Replace the
connection.
3
Re-perform the Measurement cycle test again.
Does the above test pass?
Perform the “Belt
edge learn test”.
See “Belt edge
learn test” on
page 4-267.
Contact next level
of support.
