Diagnostic information 2-73
7510
290.10 Sensor (ADF pre-registration) static jam
13
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
Step Check Yes No
1 Check the media path.
Is the media path free of media or media fragments?
Go to step 2. Remove any
media or media
fragments.
2
Check the sensor (ADF pre registration) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF pre registration.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
3
Check the sensor (ADF pre-registration) for proper
connection.
Is the above component properly connected?
Replace the
sensor (ADF
pre-registration).
Go to “Sensor
(ADF pre-
registration)
removal” on
page 4-157.
Replace the
connection.
4
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 5.
Problem solved.
5
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
