8
Check the ADF feed drive motor assembly for proper
operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF feed drv mtr.
Does the above component operate properly?
Go to step 10. Go to step 9.
9
Check the ADF feed drive motor assembly for proper
connection.
Is the above component properly connected?
Replace the ADF
feed drive motor
assembly.
Go to “ADF feed
drive motor
assembly
removal” on
page 4-141.
Replace the
connection.
10
Check the ADF registration motor for proper operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF registration drv mtr.
5. Touch Forward or reverse.
Does the above component operate properly?
Go to step 12. Go to step 11.
11
Check the ADF registration motor for proper connection.
Is the above component properly connected?
Replace the ADF
registration
motor.
Go to “ADF
registration
motor removal”
on page 4-166.
Replace the
connection.
12
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 13.
Problem solved.
Step Check Yes No
