General information 1-21
7510
Go Back
Previous
Next
The MPF/transport drive motor is a stepper motor that drives the MPF unit assembly and media transport roll.
CMYK PC cartridge drive motor assembly
The CMYK PC cartridge drive motor assembly uses dual DC brushless motors that drive the four drums in the
four PC cartridges.
K developer/transport
drive motor assembly
MPF/transport
drive motor
K drive motor
CMY drive motor
