2-216 Service Manual
7510
CMY PC cartridges nearly exhausted
CMY PC cartridges exhausted
5
Remove the NVM board from the defective upper printer
engine board and installed on the replacement upper printer
engine board or upper printer engine board currently in the
printer.
Does the error continue?
Go to step 6 Problem solved.
6
Perform a POR.
Does the error continue when the power is turned off/on
again?
Replace the upper
printer engine card
assembly.
Go to “Upper
printer engine
card assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Check the CMY PC cartridges.
Is the above component properly installed?
Go to step 2. Reinstall the CMY
PC cartridges.
Go to “PC
cartridge unit
removal” on
page 4-54.
2
Replace the CMY PC cartridges.
Does the error remain?
Go to step 3. Problem solved.
3
Perform a POR.
Does the error remain when the power is turned off/on
again?
Replace the upper
printer engine card
assembly.
Go to “Upper
printer engine
card assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Check the CMY PC cartridges.
Is the above component properly installed?
Go to step 2. Reinstall the CMY
PC cartridges.
Go to “PC
cartridge unit
removal” on
page 4-54.
2
Replace the CMY PC cartridges.
Does the error remain?
Go to step 3. Problem solved.
Step Check Yes No
