Diagnostic information 2-59
7510
Go Back
Previous
Next
243.01 Sensor (tray 2 feed-out) late jam (feeding from tray 3)
10
Perform a print test.
Does the error continue?
Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine card
assembly removal”
on page 4-91.
Problem solved.
Step Check Yes No
1 Check the media condition.
Is the media in the tray crumpled or damaged?
Replace the
damaged media with
new.
Go to step 2.
2
Check the media position.
Does the media touch the sensor (tray 2 feed-out)?
Remove the media. Go to step 5
3
Check the sensor (tray 2 feed-out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 2.
5. Touch Feed-out.
Does the display on the operator panel, change every
time the sensing area of the above sensor is interrupted
or blocked?
Go to step 5.
Go to step 4.
4
Check the sensor (tray 2 feed-out) for proper
connection.
Is the above component properly connected?
Replace the sensor
(tray 2 feed-out).
Replace the
connection.
5
Check the sensor (tray 3 feed-out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 3.
5. Touch Feed-out.
Does the display on the operator panel, change every
time the sensing area of the above sensor is interrupted
or blocked?
Go to step 7.
Go to step 6.
6
Check the sensor (tray 3 feed-out) for proper
connection.
Is the above component properly connected?
Replace the sensor
(tray 3 feed-out).
Replace the
connection.
Step Check Yes No
