Diagnostic information 2-107
7510
Go Back
Previous
Next
295.04 Too long size jam
3
Check the sensor (sheet through) for proper connection.
Is the above component properly connected?
Replace the
sensor (sheet
through).
Go to “Sensor
(sheet through)
removal” on
page 4-165.
Replace the
connection.
4
Check the sensor (ADF pre registration) for proper
operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF pre registration.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
5
Check the sensor (ADF pre-registration) for proper
connection.
Is the above component properly connected?
Replace the
sensor (ADF pre-
registration).
Go to “Sensor
(ADF pre-
registration)
removal” on
page 4-157.
Replace the
connection.
6
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to ADF
controller card
assembly
removal” on
page 4-145.
Go to step 7.
Problem solved.
7
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
Step Check Yes No
1 Check the document size.
Is the correct size document being inserted into the ADF?
Go to step 2. Insert the proper
size document
into the ADF.
Step Check Yes No
