Fuser
Heat roll
The heat roll is a hollow metal tube with a coated surface. This tube is heated by the inner heater lamp. The heat
is applied to the media passing between the heat roll and pressure roll, fusing the toner on the media.
Fuser cooling fan
Heat roll
Sensor (fuser exit)
Pressure
belt
Thumb
screws
