2-46 Service Manual
7510
202.00 Sensor (fuser exit) lag jam
12
Perform a print test.
Does the error continue?
Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-91.
Problem solved.
Step Check Yes No
1 Check the media position.
Does the media touch the sensor (fuser exit)?
Remove the
media.
Go to step 2.
2
Check the sensor (fuser exit) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch BASE SENSOR TEST.
3. Touch Media Path.
4. Touch Fuser exit.
Caution: The area around the actuator is very hot. Allow
the fuser area to cool before proceeding.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
3
Check the sensor (fuser exit) for proper connection.
Is the above component properly connected?
Replace the
sensor (fuser exit).
Go to “Sensor
(fuser exit)
removal” on
page 4-35.
Replace the
connection.
4
Check the duplex diverter gate solenoid for proper
operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer Motor Test.
4. Touch Duplex diverter gate solenoid.
Does the above component operate properly?
Go to step 6. Go to step 5.
5
Check the duplex diverter gate solenoid for proper
connection.
Is the above component properly connected?
Replace duplex
media inverter
assembly.
Go to “Duplex
media inverter
assembly
removal” on
page 4-9.
Replace the
connection.
Step Check Yes No
To Next Page
