Printer theory
Media transport
Media transport path
Media is supplied from the MPF, tray 1, 2, 3 or 4, and is transported to the printer along the media transport path
shown below.
MPF
MPFpickroll
MPF Transport Roll ASM
MPF ASM
Media feed
unit ASM
Media feed
unit ASM
Pick roll
Pick roll
Separation roll
Separation roll
Feed roll
Media transport roll ASM
Tray 1
Tray 2
Feed roll
Registration roll ASM
2nd Transfer roll ASM
Transfer belt
Heat roll
Pressure belt
Fuser unit ASM
Fuser media
exit roll assembly
Duplex media transport rollASM
Standard
media exit
Media feed
unit ASM
Pick roll
Separation roll
Tray 3
Feed roll
Media feed
unit ASM
Pick roll
Separation roll
Tray 4
Feed roll
Print exit
Standard media exit roll assembly
