Lexmark X945e MFP 7510 series User Manual

Diagnostic information 2-127
7510
Go Back
Previous
Next
846.01 Scanner communication error
846.10 Sensor (ADF width APS X) error
3
Perform a POR.
Does the error remain when the power is turned off/on?
Replace the
scanner
controller card
assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-130.
Go to step 4.
Problem solved.
Step Check Yes No
1 Check the scanner interface cable assembly connection
between the RIP card assembly and the scanner unit
assembly.
Is the scanner interface cable assembly connected properly?
Go to step 2. Replace the
connection.
2
Check all connections of the scanner controller card assembly.
Are the connections of the scanner controller card assembly
connected properly?
Go to step 3. Connect each
connector of the
scanner
controller card
assembly
properly.
3
Perform a POR.
Does the error remain when the power is turned off/on?
Replace the
scanner
controller card
assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-130.
Go to step 4.
Problem solved.
Step Check Yes No
1 Check the sensor (ADF width APS 1) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF width APS 1.
Does the display on the operator panel, change every time the
sensing area of the above sensor is interrupted or blocked?
Go to step 2. Go to step 3.
Step Check Yes No
