Lexmark X945e MFP 7510 series User Manual

Diagnostic information 2-79
7510
Go Back
Previous
Next
4
Check the media path for contaminates.
Is the media path free of excess media dust and foreign
objects such as paper clips and staples?
Go to step 5. Remove all
contaminates from
the media path.
5
Check the sensor (ADF registration) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch ADF registration.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 7. Go to step 6.
6
Check the sensor (ADF registration) for proper connection.
Is the above component properly connected?
Replace the
sensor (ADF
registration).
Go to “Sensor
(ADF
registration)
removal” on
page 4-156.
Replace the
connection.
7
Check the ADF registration motor for proper operation.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF registration drv mtr.
5. Touch Forward or reverse.
Does the above component operate properly?
Go to step 9. Go to step 8.
8
Check the ADF registration motor for proper connection.
Is the above component properly connected?
Replace the
ADF registration
motor.
Go to “ADF
registration
motor removal”
on page 4-166.
Replace the
connection.
9
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 10.
Problem solved.
10
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
