2-118 Service Manual
7510
Go Back
Previous
Next
2
Check the sensor (pick roll position HP) for operation.
1. Enter the Diagnostics Menu.
2. Touch SCANNER TESTS.
3. Touch Sensor Tests.
4. Touch Pick roll position HP.
Does the display on the operator panel, change every time the
sensing area of the above sensor is interrupted or blocked?
Go to step 4. Go to step 3.
3
Check the sensor (pick roll position HP) for connection.
Is the above component properly connected?
Replace the
sensor (pick roll
position HP).
Go to “Sensor
(pick roll
position HP)
removal” on
page 4-148.
Replace the
connection.
4
Check the pick roll position motor assembly.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Pick roll position mtr.
Does the pick roll position motor assembly raise and lower
properly?
Go to step 6. Go to step 5.
5
Check the pick roll position motor assembly for connection.
Is the above component properly connected?
Replace the
pick roll position
motor
assembly.
Go to “Pick roll
position motor
assembly
removal” on
page 4-151.
Replace the
connection.
6
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the
ADF controller
card assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-145.
Go to step 7.
Step Check Yes No
