2-250 Service Manual
7510
Go Back
Previous
Next
6
Check the registration/transport roll assembly.
Are all drive rolls on the registration/transport roll
assembly free of contamination, wear and damage?
Go to step 7. Replace
registration/
transport roll
assembly.
Go to
“Registration /
transport roll
assembly
removal” on
page 4-46.
7
Check the upper printer engine card assembly.
Replace the upper printer engine card assembly.
Go to “Upper printer engine card assembly
removal” on page 4-88.
Perform a print test.
Does the error continue?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-84.
Problem solved.
Step Check Yes No
