Repair information 4-127
7510
Go Back
Previous
Next
8. Remove the CCD card/lens assembly (E).
Note: Ensure that the white connector is plugged into the sensor (platen length APS 1) (B).
Blue connector
B
A
C
White
connector
E
D
Connector
