Lexmark X945e MFP 7510 series User Manual

Repair information 4-271
7510
Go Back
Previous
Next
7
Check the image density sensor assembly for toner
contamination.
Is the above component dirty or contaminated?
Remove and clean
the image density
sensor assembly.
See “Image
density sensor
assembly
removal” on
page 4-55.
Go to step 8.
8
Re-Perform the Skew fine setup.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Control setup cycles
5. Touch Skew fine setup
Does the above test pass?
Perform the In/Out
setup.
See “In/out
setup” on
page 4-272.
Replace the image
density sensor
assembly.
See “Image
density sensor
assembly
removal” on
page 4-55.
9
Re-Perform the Skew fine setup.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Control setup cycles
5. Touch Skew fine setup
Does the above test pass?
Perform the In/Out
setup.
See “In/out
setup” on
page 4-272.
Contact next level
of support.
Step Check Yes No
